| No. | Parameter | Unit | 1310T/ 1490+1550R | 1490T/ 1310+1550R |
1310+1490T
/ 1550R
|
1550T/ 1310+1490R |
| 1 | Operating Wavelength Range | nm | 1250~1650 | |||
| 2 | A.O.I. | degree | 45 | 0 | 45 | 0 |
| 3 | Passband (PB) | nm | 1310±50 | 1490±10 | 1260~1508 | 1549~1560 |
| 4 | Reflect Band 1(RB1) | nm | 1470~1600 | 1260~1450 | 1540~1650 | 1260~1530 |
| 5 | Reflect Band 2(RB2) | nm | - | 1530~1650 | - | 1574~1630 |
| 6 | Max. IL within PB | dB | <0.3 | |||
| 7 | Ripple within PB | dB | <0.25 | |||
| 8 | Isolation within RB1 | dB | >35 | >30(40) | >25 | >30(40) |
| 9 | Isolation within RB2 | dB | - | >30(40) | - | >30(40) |
| 10 | Operating Temperature | ℃ | 0 ~ 70 | |||
| 11 | Storage Temperature | ℃ | -40 ~ 85 | |||
| 12 | Dimension(L*W*T) | mm | Can be customized | |||
| 13 | Thickness | mm | 0.1, 0.21, 0.3 | 0.3 | 0.21, 0.3 | 0.55 |
